TEFEN Male NPT Barb Block Connector PVDF


Specifications

Part NO.

OD

Thread Size

(NPT)

L

SW

22256804021

1/4"

1/8"

29.4 mm

13 mm

22256804041

1/4"

​1/4"

34 mm

15 mm

22256804061

1/4"

3/8"

35.1 mm

18 mm

22256804081

1/4"

1/2"

40.2 mm

22 mm

22256804121

1/4"

3/4"

41 mm

27 mm

22256805021

5/16"

1/8"

29.4 mm

13 mm

22256805041

5/16"

​1/4"

34 mm

15 mm

22256805061

5/16"

3/8"

35.1 mm

18 mm

22256805081

5/16"

1/2"

40.2 mm

22 mm

22256805121

5/16"

3/4"

41 mm

27 mm

22256806041

3/8"

​1/4"

37.6 mm

15 mm

22256806061

3/8"

3/8"

38.6 mm

18 mm

22256806081

3/8"

1/2"

43.7 mm

22 mm

22256806121

3/8"

3/4"

44.4 mm

27 mm

22256808041

1/2"

​1/4"

38.5 mm

15 mm

22256808061

1/2"

3/8"

40 mm

18 mm

22256808081

1/2"

1/2"

45 mm

22 mm

22256808121

1/2"

3/4"

45.8 mm

27 mm

CONTACT US FOR MORE INFORMATION

22256804021 22256804041 22256804061 22256804081 22256804121 22256805021 22256805041 22256805061 22256805081 22256805121 22256806041 22256806061 22256806081 22256806121 22256808041 22256808061 22256808081 22256808121
